Photography by Wesley R. Elsberry

From 1982 to 1983, I worked at Media Image Photography in Gainesville, Florida. Randy Batista ran Media Image, and the space was shared with Gallery 21, run by Laurie Hitzig. Gallery 21 sold fine art poster prints and had shows of original works by North Florida artists. I had often done time exposure work, and I have a series of photos done in and around the Gallery 21 space. The one above features Laurie Hitzig in the frame, as it were.

Viewed 263 times by 65 viewers

The negative sleeve reads, “Gator Guard, 1/27/81″. I have stacks of negatives in glassine sleeves as a legacy from my job in college, which was as a staff photographer for the Independent Florida Alligator, the newspaper serving the University of Florida campus.

I recall doing my share of grip-and-grin pics and photos of visiting scholars and celebrities. But one thing that was consistently being provided by other staff photographers was “feature art”, the picture splashed on the page for no other reason than that it made people look at the paper twice. I remember just after lunch that day when the photo editor, Kim Kulish, caught me upstairs in the hall outside the darkroom and told me bluntly, “You will have feature art by 5.” OK, so he knew how to give people incentive. That still didn’t make it simple to actually deliver. Fortune favors the prepared, and I got over to campus.

Gator Guard is a drill team made up of ROTC students, and they happened to be out practicing. I have three negatives on the strip in the sleeve, the first an uninspired and uninspiring long shot down the line of students. As I recall, they did some fairly typical march maneuvers, but then they ended up in a rough circle around the drill leader, suddenly flipping their bayonet-tipped drill rifles inward, stopping just a few inches from the drill leader’s face. That was different, and I got a photo, but the angle was such that I could only see about three of the bayonets. I got a better angle on the group as they repeated the drill, and got the third photo, the one shown above. So I did actually have something for Kim when I got back to the Alligator, and they ran the shot and put it out on the AP Wire, making it the first photo of mine to get broad distribution.

Viewed 485 times by 100 viewers

Taken around 19781986, Nikon F2A and Nikkor AIS 24mm f/2.8 lens. Fountain just outside the auditorium at Florida Southern College. I’m on the left, and my friend Bill Robinson is on the right.

The slide was scanned on an Epson Perfection V500 scanner. Given the age of the slide, I’m pretty pleased with the result.

Correction on the date: I found some other slides taken at the same time that were labeled as 1986. Still going back a ways, but not quite so far. It makes more sense, though, given that I didn’t take up color slides as a common film choice until the early 1980s.

Viewed 791 times by 153 viewers

The Panoramio photo sharing service is linked to Google Earth. You can upload images to Panoramio, geotag them (pick a spot on the map where your picture was taken), and they may be selected for viewing via Google Earth. They tend to only select those photos that are primarily landscapes. If a person or animal is the central element of the photo, it is unlikely to be selected for Google Earth. The selection process takes a while, with about a monthly schedule for inclusion of new photos into Google Earth, so don’t get impatient.

I’ve uploaded some of my photos to Panoramio.

Viewed 1430 times by 279 viewers

At FixYa.com, a surgeon asked about using the Fuji S2 with a ringflash for surgical photos. Red is easy to oversaturate on the Fuji S2, and this leads to photos that don’t yield the distinctions between tissue color that he is looking for. Here is the advice I gave:

The Fuji S2 sensor is noted for this red sensitivity. Here’s a few different approaches to getting the shot with the S2, all of which require some experimentation.

1. Set the “Color” and “Tone” Function options to “ORG”. Underexpose the shot. Progressively change the exposure compensation downward until when checking the histogram, the red channel does not show saturation at the high end. Advantages: this is the simplest approach to getting the picture. Disadvantages: the S2 already had a fairly limited dynamic range, and this will make things worse for the parts of the photo that are not red. For the surgical setting and use of a ringflash, this may not be much of a disadvantage, since a lot of the stuff of interest will be red, and ringflash illumination generally is of lower contrast than directional lighting.

2. Set the “Color” and “Tone” Function options to “ORG”. Use a custom white balance. The idea here is to have the camera adjust the red channel sensitivity itself, and leave the blue and green channels alone. To do this, start with several sheets of white paper and a red or pink marker or highlighter. Scribble with the marker across a sheet, then use that to set a custom white balance. Take a test shot of the red stuff that has been problematic, and see whether the histogram for the red channel shows that there is no saturation at the high end. Repeat this with progressively more red or pink on each sheet used to set the custom white balance until you find the custom white balance that takes enough of the edge off the red channel response. Alternative: I just tried out making a gradient across an 8.5×11″ sheet of paper going from white to about 30% red saturation. I can set more or less red adjustment in a custom white balance just by pointing the camera at different parts of the page. This seems to work OK for me. Advantage: can allow the full dynamic range of the sensor to be used. Disadvantages: the experimentation period is likely to take a while to get the best results, and the final images are unlikely to look completely natural.

3. Set the “Color” Function option to “B/W”. Use a green or cyan filter on the lens to cut the amount that the red color channel contributes to the final image. Advantages: this is fairly simple as an approach. A similar post-processing technique can be applied to the photos that you already have, by nulling out the red channel contribution and desaturating the blue and green channels to produce a grayscale image. Disadvantages: you lose the color information entirely. Since much of what you want information about is colored red anyway, the organs are likely to appear quite dark when only taking the blue and green channel contributions to the image.

Viewed 1465 times by 296 viewers

Over on FixYa.com, I answered a question posed about how to set the white balance on a camera when using electronic flash indoors. Here’s my answer:

There are three possible solutions for you:

1. Just use the Daylight (direct sun) white balance setting. Electronic flash is typically close to the direct sunlight setting for white balance. Advantages: it is simple. Disadvantages: if you are balancing electronic flash with ambient light, you are likely to have an odd mixture of lighting, with the ambient lighting tending toward red (if incandescent) or green (if flourescent).

2. Get a Wratten 85 color correction gel that you can cover your flash’s head with, and use the Tungsten white balance setting. This will bring your flash output into line with existing incandescent light sources. Advantages: almost as simple as (1), and allows you to come close to matching a common indoor lighting situation. This will produce more natural-looking environmental shots if you balance the flash and incandescent ambient light contributions to the exposure. Disadvantages: large gel filters get expensive. You may be able to obtain something close to the Wratten 85 color correction filter from a theater supply house more cheaply. Roscolux #3408 is slightly weaker and #3411 is slightly stronger than the Wratten 85. If you have to balance flash with flourescent light sources, try a Roscolux in the cyan series leading to #4360. Some experimentation is likely to be required. The place I looked online offered the Roscolux in 20×24″ sheets for about $7 per sheet, a bargain compared to the optical-grade Wratten filters.

3. Set a custom white balance. This is not too difficult, and it will definitely provide the best approximation to your desired white balance that you will obtain in the field. Advantages: this will allow you to reproduce white accurately even with mixed lighting sources. Combine with gel over flash of (2) for the very best approach to balanced flash/incandescent lighting situations. Disadvantages: requires a “white” target (can be a neutral gray photo card, for example) and some additional time before a photo session.

You can obtain some striking effects by purposely mixing color temperature light sources. But day in and day out, getting a balanced shot is a skill that it pays to cultivate.

Viewed 1471 times by 289 viewers

Originally posted to the “Nikon SLR Forum” on the DPReview site.

Moon wrote:

> DMillier wrote:
> > Yes when the frame enlarges, the pixels enlarge. But SO DOES THE
> > SIZE OF THE OPTICAL IMAGE!

> > If your one pixel on a small sensor is positioned so it covers say
> > 1 sq inch of the subject and you enlarge the pixel by say x10 what
> > happens? Absolutely nothing if you use a different lens matched to
> > the new sensor size. This is because the new optical image will
> > also be x10 larger so your one (x10 enlarged pixel) will still
> > cover 1 square inch of your (now x10 enlarged) subject...

> I follow what you are saying, but my presumption is that we were
> discussing a 35mm system. The D/1/x/h/100/30/60, 1D, etc. are based
> on 35mm systems and, as such, use the same lens system. Assuming
> the same lens is used from one sensor size to the next and the
> frames were compositionally identical, resolution would be lost.

IIRC, the formula for working out resolution with film is

1/res_total ~= 1/res_lens + 1/res_film

where resolution is given in lines/mm or some similar units.

So lets say we’ve got a lens with res_lens = 60 l/mm, and calculate numbers for CCD pixel density given Ron’s sensor sizes. For 6MP on a 15×23mm sensor, we get 1.71e5/mm, and for a 24×36mm sensor we get 6.94e3/mm. I’m going to just equate pixel spacing with lines/mm here; since this is just a before/after comparison this shouldn’t be a problem. So we have res_small = 132 l/mm and res_large = 83.3 l/mm (square root of the pixel density figures).

res_total_small ~= 1/60 + 1/132 = 41.2 l/mm

res_total_large ~= 1/60 + 1/83.3 = 34.9 l/mm

That’s a distinct drop in resolving power, yes?

But that wasn’t the whole claim made. The whole claim concerns how well an *identical composition* is resolved under the two different scenarios. And that takes us to a slightly different concept of resolution, one that is common in videography, which is the total number of lines of resolution that the system is capable of. This we can approximate by taking into account the sensor sizes and the lines/mm figures we just calculated. Again, we’re just looking at a before/after comparison, so this should also not be a problem.

total_lines = l/mm * mm

total_lines_small = 41.2 l/mm * 23mm = 948 lines

total_lines_large = 34.9 l/mm * 36mm = 1,256 lines

Hmm. It seems to me on the math that the larger sensor has the edge over the smaller sensor given the same number of pixels in both. This also explains why lenses that were adequate for use with 35mm film may not be adequate for the small sensors of the current [posted around 2003, IIRC] crop of DSLRs (D100, S2, D60). In order to get comparable performance, one needs a res_lens that is significantly higher. (To get the same total lines figure for the case above, for instance, one needs a lens capable of resolving 93 lines/mm on the smaller sensor to match the performance of a lens that resolves 60 lines/mm on the larger sensor.)

But perhaps I’ve remembered the formula wrong or messed something up in applying it. If so, I’d appreciate a correction.

Viewed 1548 times by 320 viewers

I picked up a 52mm 720nm cut-off infrared filter to give infrared photography a try. This is fun stuff. The 52mm filter is something I can fit on the Canon S2 IS with adapter, Fuji e900 with adapter, or my set of manual focus Nikkor prime lenses to go on the Nikon D2Xs.

In Googling on the topic, there’s a page that comes up saying that the Fuji e900 can’t be used for infrared. I’m not sure what that meant, but here are two photos showing the same scene, both taken minutes apart with the e900, one with the IR filter on and the other as normal.

Normal view:

Infrared view:

OK, neither of the above are the result of a single exposure. Both were done as a bracketed series of exposures imported into the Qtpfsgui HDR (high dynamic range) program, then tonemapped to produce a low dynamic range image. I was using a Raynox 0.66x wide angle accessory lens for each, and that apparently introduced softness at the corners. Additionally, I swapped the red and blue channels in the IR image to get a more appealing color scheme. I used ImageMagick for the RB channel swap operation:


convert ir_horiz_pond_01.jpg -recolor " 0 0 1 0 1 0 1 0 0 " ir_h_pond_01_rbswap.jpg


So far, it seems that getting more than monochrome-type results from IR on all three of the cameras requires setting a custom white balance. Fortunately, that is doable on all three. I just used a blank sheet of paper, but I suspect that more exploration is probably in order on that score. The Canon and Fuji are somewhat easier to use for IR photography because they can display an image based on what is received at the sensor. With the Nikon D2Xs, it does not have “live view” capability, so I can either be screwing the filter on and taking it off continually, or I can take proof pictures and see what was captured using the LCD display.

In order to get an exposure short enough for handheld IR photos, I had to run the ISO on the e900 up to 800. Even then, it was pretty long for handheld photos out at the pond in late afternoon.

Here are some results of single exposures in the front yard:

Viewed 4090 times by 685 viewers

I’ve recently set up accounts on Flickr and Zooomr. I’ve uploaded some picks from my July visit to the Georgia Aquarium to each. So far, there’s been small activity on either, but what little action there is is happening on Zooomr.

Shark and surface by Wesley R. Elsberry on Zooomr

Since I’m new to the photo sharing phenomenon, anybody who’d care to share some tips on making it work, please feel free to comment.

Viewed 4027 times by 673 viewers

Photos from the CCCC AKC Agility Trials at Pa-Wa-Pi near Williamston, Michigan are up:

Click here: Photos from Day 1, July 26

Click here: Photos from Day 2, July 27

I took pictures in Ring 2 on the 26th, and in Ring 1 on the 27th. Raymond Dutton took photos in the other ring each day, so be sure to visit his website for those photos.

Note on photographic gear: I’m using a Nikon D2Xs camera for taking photos here. While digital photography is substantially more economical than film photography, there are expenses involved. If I recall correctly, my camera is rated mechanically to provide about a quarter of a million shutter activations. After that, I can expect to have a costly repair to replace the shutter and mirror mechanism, or, more realistically, it will be time to replace the camera with a new one. I can take the amount paid for my camera, the number of exposures I took this weekend, and the total shutter activations and determine a bottom-line amount of wear-and-tear placed on my camera this past weekend: about $72. That’s essentially an up-front investment I’ve made in taking photos for the event. I also now have about 13 gigabytes of storage occupied by the photo files, and I need to try to store those archivally so that I can fulfill orders over at least the next six months. There’s the server space and internet connectivity to allow online browsing and ordering. I enjoy taking photos, and especially enjoy taking good photos, but I need a little assistance at least if I am going to continue doing so. If you see a good photo here that is of a friend or acquaintance, would you please consider at least dropping them an email to let them know that it exists? I would appreciate that greatly.
